E-bike

Charger
Custom charger, 42V4A w/ Rosenberger plug, 100-240V

Wiring Harness
Custom wire harness

UI/Remote
MasterMind TCD, w/handlebar remote, built-in anti-theft feature, Bluetooth® connectivity, customizable display pages

Battery
Specialized 710Wh integrated battery

Motor
Specialized 2.0, 70Nm torque, custom tuned motor, 250W nominal

Frameset

Seat Binder
Alloy, bolt-type, 34.9mm

Frame
E5 Aluminum, bottom bracket motor mount, fully integrated &lockable downtube battery, internal cable routing, lock and front rack mount

Suspension

Fork
SR Suntour XCR34-Boost, 110mm Travel

Cockpit

Saddle
Bridge Sport, Steel rails, 155mm

Stem
Specialized Stealth Stem, alloy, 14 deg, 31.8mm, integrated TCD mount

Grips
Specialized Trail Grips

Handlebars
Specialized Trail, 6061 alloy, 8-degree backsweep, 6-degree upsweep, 27mm rise, 31.8mm clamp, S 720mm, M-XL
750mm

SeatPost
TranzX Dropper, 30.9mm, S: 100mm, M-XL: 120mm

Brakes

Front Brake
Tektro HD-T280, hydraulic disc, 180mm

Rear Brake
Tektro HD-T280, hydraulic disc, 180mm

Drivetrain

Chainrings
40T

Crankset
Custom Alloy Forged Crankarms, Isis, 170mm, Cl 50.73mm, BCD 104mm

Chain
Shimano LG500

Cassette
Shimano Cues 9-speed, 11-41

Rear Derailleur
Shimano Cues 9-speed, Shadow design

Shift Levers
Shimano Cues 9-speed w/ gear indicator

Wheels & tires

Front Hub
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h

Spokes
DT Swiss Industry

Front Tire
Ground Control, 2Bliss Ready, 29×2.35″

Rear Tire
Ground Control, 2Bliss Ready, 29×2.35″

Rear Hub
Specialized Alloy Rear Hub Disc, Sealed Cardridge Bearings, 6-Bolt, 12X148mm Thru-Axle, 32H, Hd Steel Fhb

Inner Tubes
Standard 40mm SV 29×1.75-2.4

Rims
Stout XC 29, 25mm internal width, disc-specific

Accessories

Bell
Simple bell

Pedals
Specialized Body Geometry Fitness, Platform, Plastic

Bike Lock
Turbo System Lock
