Kuvaus

Technical Specifications

Frameset

Fork
A1 Premium Butted Alloy, Alloy steerer, 15×110 mm, W/Mini Fender

Frame
A1 Premium Butted Alloy, unisex frame, internal cable routing, 148mm thru-axle, 30.9mm dropper post ready, replaceable derailleur hanger compatible

Seat Binder
Bolt-type, 34.9mm

Brakes

Rear Brake
Promax DSK-926, Hydraulic Disc Brake, 160mm Rotor, Adjustable Reach

Front Brake
Promax DSK-926, Hydraulic Disc Brake, Adjustable Reach

Drivetrain

Chainrings
30T

Crankset
Forged Alloy, 140mm length, narrow Q-factor, w/ chainguard

Chain
KMC X9EPT, 9-speed, anti-corrosion coating w/ reusable Missing Link™

Bottom Bracket
Square-tapered, 68mm

Shift Levers
microSHIFT Advent SL-M6190, 9-speed , short reach triggers for easy operation

Rear Derailleur
microSHIFT Advent, 1×9 w/ clutch

Cassette
microSHIFT Advent, 9-speed, 11-42t

Wheels & tires

Rims
Alloy, 16mm depth, 25mm internal width, 28H

Rear Hub
Alloy, 6-Bolt, 28H, 12×148 Boost, 11-speed compatiable

Front Hub
Alloy, 6-Bolt, 28H, 15×110 Boost

Front Tire
Kicker Wirebead 24X2.1

Rear Tire
Kicker Wirebead 24X2.1

Inner Tubes
Presta, 32mm valve

Spokes
Stainless, 14g

Cockpit

Saddle
Bridge Kids Saddle, 130mm

Handlebars
Double Butted Alloy, 40mm rise , 11deg back sweep, 2.5deg up seep, 31.8mm, 620mm

Grips
Specialized Trail Grips, lock-on

SeatPost
Specialized, 6061 alloy, 2-bolt clamp, 0mm setback, 30.9mm

Stem
Stout 3D-forged alloy, 31.8mm, 6-degree rise

Accessories

Pedals
Nylon platform w/ reflectors
