Kuvaus

Frame
Alloy Frame & Link
Virtual 4 link kinematic VLK
29×2.6 / Boost 148x12mm UDH
150mm travel / Bosch Gen4 / Integr. removable Battery
1.8″ Headtube, Central Kickstand Mount
Integr. Cable

Travel
Front & Rear: 150mm

Fork
RockShox 35 TK Air
15x110mm QR axle / 1.8″ Tapered Steerer
Reb. Adj. / 2 Modes / Lockout / 150mm travel / E-Bike

Rear Shock
X-Fusion NUDE eRIDE Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Reb. Adj.
Travel 150-100-Lockout / 205x55mm

Remote System
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 modes

Drive Unit
Bosch Performance CX
EU: 25kmh / INT: 20mph

Battery
PowerTube 625Wh

Display
Bosch LED Remote & Kiox 300

Charger
4A Charger

Rear Derailleur
SRAM NX Eagle / 12 Speed

Shifters
SRAM SX Eagle Single Click

Crankset
FSA CK-745 / 165mm / 34T

Chainguide
e*thirteen / e*spec Slider

Chainring
SRAM Eagle 34T DM / Steel

Chain
SRAM SX Eagle

Cassette
SRAM PG1210 / 11-50T

Brakes
SRAM DB8 4 Piston Disc

Rotor
SRAM Centerline CL Rotors 200mm F&R

Handlebar
Syncros Hixon 2.0 Rise / Alloy 6061D.B.
20mm rise / 8° / 760mm
Syncros Comfort lock-on grips

H’stem
Syncros AM2.0 / 6061 Alloy
31.8mm / 4° / 1 1/8″

Seatpost
Syncros Duncan Dropper Post 2.5
31.6mm / S size 125mm / M size 150mm / L size 170mm / XL size 200mm

Seat
Syncros Capilano

Headset
Acros / 1.8″
ZS66 OD74 / 12mm Adapter / integr. Cable

Hub (Front)
Formula CL-811 / 15x110mm

Hub (Rear)
Formula CL-148S / Boost 148x12mm

Spokes
Stainless Black

Rims
Syncros MD30 / 32H / 30mm / Pin Joint

Tubeless ready
Front Tire
Maxxis Rekon / 29×2.6″ / 120TPI Foldable Bead
EXO+ / TR Tubeless ready
3C Maxx Terra

Rear Tire
Maxxis Rekon / 29×2.6″ / 120TPI Foldable Bead
EXO+ / TR Tubeless ready
3C Maxx Terra

Lights
Syncros integrated rear fender light
Front Light Cable pre-installed

Approx weight in KG
26.1 (with tubes)

Approx weight in LBS
57.54 (with tubes)

Max. System Weight
128kg

The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
