Colors
Metal

Frame
ALUXX-Grade Aluminum, disc

Fork
SXC32-2 RL, air spring, QR, alloy steerer XS: 80mm travel (27.5) S: 100mm travel (27.5) / 100mm travel (29) M: 100mm travel (27.5) / 100mm travel (29) L: 100mm travel (29)

Shock
N/A

Handlebar
Giant Connect Trail, 31.8mm XS: 670mm (27.5) S: 670mm (27.5) / 670mm (29) M: 750mm (27.5) / 750mm travel (29) L: 750mm (29)

Grips
Giant Sole-O

Stem
Giant Sport, 7-degree XS: 40mm (27.5) S: 40mm (27.5) / 40mm (29) M: 50mm (27.5) / 50mm travel (29) L: 50mm (29)

Seatpost
Giant Sport, 30.9 XS: 300mm (27.5) S: 300mm (27.5) / 375mm (29) M: 375mm (27.5) / 375mm travel (29) L: 375mm (29)

Saddle
Liv Sport

Pedals
MTB caged

Shifters
Shimano Deore M6100, 1×12

Front Derailleur
N/A

Rear Derailleur
Shimano Deore M6100

Brakes
Shimano Deore BR-MT200, hydraulic, Shimano RT-10 rotors [F]180mm, [R]160mm

Brake Levers
Shimano Deore BL-MT200

Cassette
Shimano Deore M6100, 10×51

Chain
KMC X12

Crankset
MPX-CR094S alloy, 30t XS: 165mm (27.5) S: 165mm (27.5) / 170mm (29) M: 170mm (27.5) / 170mm travel (29) L: 175mm (29)

Bottom Bracket
cartridge

Rims
Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width

Hubs
Shimano, sealed bearing

Spokes
stainless, 14g

Tires
Kenda Booster 27.5 or 29×2.4″, wire bead

Extras
2.4″ max tire size
