Kuvaus

Tekniset tiedot

Runko
ALUXX-grade aluminum, disc

Haarukka
SXC32-2 RCL, air spring, thru axle, steel steerer, 15×110 XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29) M:100mm travel (29) L: 100mm travel (29) XL: 100mm travel (29) XXL: 100mm travel (29)

Iskunvaimennin
N/A

Ohjaustanko
Giant Connect Trail, 31.8mm XS: 690mm (27.5) S: 690mm (27.5) / 750mm (29) M: 780mm (29) L: 780mm (29) XL: 780mm (29) XXL: 780mm (29)

Ohjainkannatin
Giant Sport, 7-degree XS: 40mm (27.5) S: 50mm (27.5) / 50mm (29) M: 60mm (29) L: 70mm (29) XL: 80mm (29) XXL: 90mm (29)

Satulatolppa
Giant Contact Switch Core, 30.9 XS: 100x350mm (27.5) S: 100x350mm (27.5) / 100x350mm (29) M: 120x400mm (29) L: 120x400mm (29) XL: 120x400mm (29) XXL: 120x400mm (29)

Satula
Giant ErgoContact Trail

Polkimet
MTB caged

Vaihdevipu
Shimano Deore M6100, 1×12

Etuvaihtaja
N/A

Takavaihtaja
Shimano Deore M6100, clutch

Jarrut
Shimano BR-MT200, hydraulic, Shimano RT-10 rotors [F]180mm, [R]160mm

Jarrukahvat
Shimano BL-MT200

Rataspakka
Shimano Deore M6100, 10×51

Ketjut
KMC X12

Kampisarja
ProWheel MPX, 32t (27.5) or 30t (29) XS: 165mm (27.5) S: 165mm (27.5) / 170mm (29) M: 170mm (29) L: 170mm (29) XL: 175mm (29) XXL: 175mm (29)

Alakiinnike
cartridge

Vanteet
Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width

Navat
[F] Shimano, sealed bearing, 15×110 thru axle, [R] 12×142 thru-axle

Pinnat
stainless, 14g

Renkaat
Maxxis Rekon 27.5×2.4″ or Maxxis Rekon Race 29×2.4″, wire bead
