Technical Specifications

FRAMESET

Frame
M5 alloy chassis and rear-end, Mixed wheel Trail Geometry, threaded BB,12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 160mm of travel

Seat Binder
Alloy, 38.6mm

Suspension

Rear Shock
FOX FLOAT X Performance, Rx Trail Tune, EVOL Air sleeve, 2-position lever w/ LSR adjustment, 230x60mm

Fork
FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset, 160mm of travel

COCKPIT

Stem
Alloy Trail Stem, 35mm bar bore

Handlebars
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 800mm width

Grips
Deity, Knuckleduster, Black

Saddle
Body Geometry Bridge Comp, hollow Cr-Mo rails, 143mm

SeatPost
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9mm, S1:125, S2: 150mm, S3/S4/S5: 170mm

BRAKES

Front Brake
SRAM Code R, 4-piston caliper, hydraulic disc, 200mm

Rear Brake
SRAM Code R, 4-piston caliper, hydraulic disc, 200mm

DRIVETRAIN

Rear Derailleur
SRAM NX Eagle, 12-speed

Shift Levers
SRAM NX Eagle, trigger, 12-speed

Cassette
SRAM NX Eagle, 12-speed, 11-50t

Chain
SRAM NX Eagle, 12-speed

Crankset
SRAM NX Eagle, DUB, 170mm

Chainrings
32T

Bottom Bracket
SRAM DUB, BSA 73mm, Threaded

WHEELS

Rims
Specialized 29, hookless alloy, 30mm inner width, tubeless ready

Front Hub
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h

Rear Hub
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h

Spokes
DT Swiss Industry

Front Tire
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29×2.3″

Rear Tire
Butcher, GRID TRAIL casing, GRIPTON® compound, 27.5×2.3″

Inner Tubes
Standard, Presta Valve
